Lower Temperature Plasma Sterilizer
• New Normal Sterilization Protocol – Enhancement of customer confidence in dentistry
The STERLINK® FPS-15s Plus sterilization system is a low-temperature plasma sterilizer to inactivate microorganisms for a broad range of metal and nonmetal medical devices and surgical instruments at low temperature. This product is reliable and provides a variety of methods of sterilization.
STERLINK® can sterilize medical devices by diffusing hydrogen peroxide vapour into the chamber or pouch. It rapidly sterilizes medical instruments and materials without leaving toxic residues. All stages of the sterilization cycle do not damage compatible instruments which are sensitive to heat and moisture.
This sterilizer can be used for metal and non-metal medical devices and can sterilize instruments with high lumen characteristics and micro-sized equipment.
It consistently provides the Sterility Assurance Level (SAL) of 10-6, as defined by U.S. Food and Drug Administration (FDA) and international standards, only when used within the materials and geometric requirements given.
The devices have been pre-validated to the SAL of 10-6 based upon high resistance conditions, including lumens within the claim lengths and mated surfaces.
ITS™ – Instrument Tracking System
Instrument Tracking System is a real-time sterilization monitoring system. Analyze the actual usage data of STERPACK®, STERPACK® Plus and STERLOAD® – provide them as device diagnostic tools. Provide advanced service that accurate data analysis immediate delivery to end-users.
- ITS™ allows real-time monitoring which enables before service and worry-free usage because problems are tracked and resolved remotely.
- ITS™ securely records sterilization data in Plasmapp’s main server.
- ITS™ monitors operation status of every sterilizer for on-time and accurate maintenance care.
- ITS™ provides remote software update to maintain STERLINK® with most updated software.
- Easy to use ITS™ mobile application allows direct access to sterilization records and sterilizer control.
Fast Sterilization
- Smart Ready™ allows auto detection of moisture and pre-drying
- Just touch and start sterilization
- Automatic mode selection with individual barcode on cassette
Convenient POWER SAVING
- Sleep mode (Heater off)
- Screen saver for LCD display
Eco-Friendly
- Decomposing residual H2O2 into WATER and OXYGEN
- Equipped with O3 purifying filter
Perfect DISINFECTION
- Improved sterile reliability with HEPA filter
- Easily replaceable
Model : FPS-15sp
| Size | 433 x 614 x 437 (W x D x H, unit: mm) |
|---|---|
| Chamber | 264 x 410 x 125 (W x D x H, unit: mm) |
| Capacity | 14 Litre |
| Weight | 67 kg |
| Input | 100-120 / 220-240 VAC, 50/60 Hz |
| Power | 1 kVA |
| Class | Class IIb (Rule 15, Annex IX of MDD 93/42/EEC) |
| Temperature | Less than 57℃ |
| Sterilant (58% H2O2) | Pouch Mode-STERPACK®, Pouch Plus Mode- STERPACK® Plus, Chamber Mode-STERLOAD® |
